Innokin Kroma 217 Kit can be powered by either a single 18650/20700/21700 battery with max 100W output on the 21700. The device includes type-C charging although we would always advise charging your batteries in an external charger like these Xtar chargers. Innokin have included key features like Coil + which vibrates the coil slightly after use and heats it a very small amount to help replenish the liquid in your coil faster minimising the chance of dry hits. The Kroma 217 also has the refresh feature that can be activated to refresh a coil that might be tasting a little off or perhaps on its way out in your opinion. Refresh mode will hopefully give you a little longer out of the coil before you have to ultimately put a new coil in your tank. Even with these features using the device is kept simple with a Variable Voltage or varibale Wattage mode.

The Z Force tank from Innokin utilizing the ZF or Z Force coils for Direct to Lung to Restricted Direct to Lung Sub Ohm vaping. Z Force coils feature DuoPrime mesh technology never seen before in a coil. There is an inner coil that heats up fast for maximum flavour and an outer mesh that heats at lower power which aids in the wicking process. The end result is a coil that should never dry hit. Making the coils last and taste better for longer.

The tank is easily filled from the top and features a spring loaded juice control that automatically shuts when you remove the coil making swapping the coil with juice in the tank simple.

When the coil needs changing unscrew the base of the tank and pull the coil out. Put a few drops on and in the new coil and simply push in place. This reopens the juice flow. Take a few draws on the tank without pressing power on your battery of choice and it is then ready to vape

Specifications:

Size: 132x45x30mm (including tank) / 86x45x30mm (without tank)

Z Force Tank

• Size: 46 x 45 x 30mm (With Tank)
• Tank Capacity: 2ml as sold (5ml with Z Force Bubble Tank sold separately)
• Resistance & Wattage Range: ZF Coils DuoPrime 0.3 Ohm (30-45W) or 0.2 Ohm (50-80W)
• Coil Material: KAL
• Spring loaded automatic juice flow control
• Glass Replaceable: Yes
• Airflow: Bottom Airflow, Adjustable
• Wicking Material: Cotton Flax
• Filling: Slide Top-Fill
• Z Force 810 drip tip (removable)

Kroma 217 Mod

• Size: 86x45x30mm
• Battery: Single External 21700 / 20700 / 18650 (with adapter)
• Wattage Range: 6-100W (21700 Battery) / 6-80W (18650 Battery)
• Voltage Range: 1V - 7.5V
• Coil + and Refresh user modes
• Modes: Variable Wattage, Variable Voltage
• Temperature Control: No
• Cut-Off Time: 3-18s Adjustable
• Tank Threading: 510
• Max Output Current: 28.5A (18650) / 32A (21700)
• Resistance Range: 0.1 - 3.5 Ohm
• Body Material: Zinc Alloy
• Thread Material: Stainless Steel
• Charging Current: 5V / 1.7A

Contents:

• 1 x Innokin Kroma 217 Mod
• 1 x Z-Force Tank
• 1 x 18650 adapter
• 1 x Type-C Charging Cable
• 1 x Innokin ZF 0.3ohm Coil
• 1 x Innokin ZF 0.2ohm Coil
• 1 x Spare Parts

For devices that use external cells.

It is not recommended that users charge their separate cell devices with a usb lead in to the device. These devices can be charged via usb as an emergency measure but is not recommended as a permanent solution. This is not a line to sell chargers there are significant reason why it should be done externally. Do not assume that it is safe. These batteries are not made for vaping and the manufacturer has no idea what cells you are using. Best to use the safer solution of a named quality charger.

1. Most vapes cannot balance charge more than one cell. One cell is charged and then after that the next cell is charged. All of the drain, excess heat and over use of that one cell causes strain on that 1st battery in the vape and ultimately leads to the demise of that 1 battery leading to the need of a new pair. If lucky it will just stop working if unlucky the cell may go into melt down
2. If your batteries are not the same age, ie the same amount of charges, the same amount of use and charged together for their whole lives then they are unbalanced. Meaning they cannot deliver the high output required by your vape. This will lead to low performance and low battery life.
3. External chargers let you monitor the charge going in to your cells. Good quality chargers will put what is needed in as opposed to as much as possible as fast as possible which can caused issues. A good charger will slow the charge rate down to recondition a bad cell. Internal charging will not do this. Using a good external charger could mean your batteries getting you through a day away from your charging equipment or not. Ultimately it is up to you how safe you want to be. Yes an external charger may sound like a hassle to you but it depends on the risks you want to take.

Please make sure your external cells have perfectly intact wraps on them If they have any of the metal showing under the wrap or the insulator on top please either re wrap or buy new cells PS This is not to scare you If you have any doubts about your charging routine just ask. Batteries get warm when they charge but if they are red hot then its time to look into it
